DESCRIBE
◪Size, configuration, and border color can be customized;
◪Right angle series and rounded series optional;
◪Adopting screen-by-picture technology;
◪Mounting direction, horizontal and vertical optional;
◪Publish multiple ads or videos at the same time;
◪Built-in high transparent tempered glass (2-6 mm ), perfectly integrated into all kinds of applications, as protection layer
to prevent lcd/led panel being broken or distorted;
◪Applications: Shopping mall, exhibition halls, hotels, restaurant, chain stores, airport, information center, end user
terminals and many other places;
Display
|
Panel
|
33.1″
|
Model
|
a-Si TFT-LCD
|
|
Active area
|
594mm(H)x594mm (V)
|
|
Ratio
|
>3:1
|
|
Resolution
|
943*943
|
|
Display color
|
16.7M
|
|
Dot pitch
|
0.315×0.315 mm (H×V)
|
|
Brightness
|
500CD
|
|
Viewing angle
|
178°
|
|
Response time
|
8ms
|
|
Refresh frequency
|
60HZ
|
|
Language
|
Chinese/English
|
|
Interface |
Video interface
|
N/A
|
Audio interface
|
N/A
|
|
Other interface
|
N/A
|
|
System
|
CPU
|
ARM Cortex-A17
|
RAM
|
2G DDR3
|
|
Internal memory
|
8G EMMC
|
|
WIFI
|
2.4G WIFI 802.11b : DQPSK, DBPSK, CCK 802.11g/n : 64-QAM,16-QAM, QPSK, BPSK
|
|
Bluetooth
|
N/A
|
|
Network
|
LANX1
|
|
Interface
|
TF Card×1/USB×2 DCIN×1 OTGX1 MICX1
|
|
Operation system
|
Android 7.1
|
|
Power |
Power supply
|
~AC 100-240V 50/60Hz
|
Power consumption
|
38W
|
|
Standby power consumption
|
≤0.1W(Board only)
|
|
Other |
Storage temperature
|
-20–60°
|
Speaker
|
1×1.3W
|
|
Dimension
|
647×647×24.5mm
|
|
Weight
|
10.4KG
|
|
Accessories |
Remote control
|
N/A
|
Power adapter
|
AC 12V/5A
|
